Lux 4 Lighting Tower
Compact Solar Lighting Tower Built to Cover Larger Areas, Every Day, Without Intervention
The Lux 4 is a solar-powered industrial lighting tower built for sites that need to cover serious ground after dark without generator fuel or daily manual operation. Four 80W high-efficiency LED lights run on a 14-hour duty cycle, engineered for full shift coverage every day through winter. The astronomical clock controller turns the lights on at dusk and off at dawn automatically, with lighting and solar settings adjustable manually or via Bluetooth smart controller.
At 1,950kg on a concrete base it handles exposed and off-road conditions without shifting. The hydraulic folding solar array and guarded 6m telescopic mast deploy with a single person. Forklift pockets in the base mean repositioning takes a 2.5T forklift and a few minutes.
- GUARDED TELESCOPIC MAST
- ADJUSTABLE POSITIONING LIGHTS
- DURABLE POWDER-COATED STEEL FRAME
- FOLDING SOLAR ARRAY
- COMPACT AND FORKLIFT-MOVEABLE
- A HUGE 45 HOUR RUNTIME ON BATTERY ONLY
See It in Use
Specifications
- Run time on Battery Only
- 45 hours
- Design Duty
- Designed to operate 14 hours a day every day including winter. 100% up time usability.
- Control
- On/Off and Auto. Operating by an astronomical clock turning on and off with dawn and dusk.
- Mass
- Lux 4 - 1,950 kg
- Base Type
- Concrete Base
- Lights
- 2/4 x 80W High-Efficiency LED
- Lumens
- Lux 4 - 58,800
- Mast Type
- 6m Cable Actuated Telescopic
- Supported Wind
- 100km/h if deployed, 145km/h stowed
- Battery Redundancy
- Up to 4 Days
- Solar Panels
- Lux 4 - 4 x 415W
- Batteries
- Lux 4 - 14.4 kWh 2 x 48V 150Ah LiFePO4
Why Choose This Product
Runs Itself, Dawn to Dusk, Every Day
The astronomical clock controller turns the Lux 4 on at dusk and off at dawn without manual input. Set it up, walk away and it operates on schedule. Lighting and solar settings are adjustable manually or via the Bluetooth-enabled smart controller if conditions or requirements change.
45 Hours on Battery, Zero Sunlight
Forty-five hours of battery runtime with no solar input keeps the Lux 4 running through extended overcast periods without intervention. Designed to operate 14 hours a day every day including winter, 100% uptime usability.
Four Lights for Serious Coverage
Four 80W high-efficiency LEDs on a 6m telescopic mast cover a significantly larger work area than a two-light setup. For open areas, large work zones or sites running multiple activities overnight, the Lux 4 handles the ground in a single unit.
Single-Person Setup
The hydraulic folding solar array and guarded telescopic mast are engineered for safe, single-person deployment in challenging environments. No crew required to get it operational.
Built for Industrial Sites That Run After Dark
Mining
Overnight operations, shift work and remote drill sites requiring consistent, unattended lighting across large open areas without generator logistics.Civil Construction
Active work zones and access points on civil projects running night shifts or extended hours where wider coverage is needed from a single unit.Agriculture
Machinery maintenance, storage facilities and work areas on large properties where mains lighting isn't available and coverage area matters.Defence & Government
Remote installations and forward deployments requiring self-sufficient, zero-emission lighting that operates without daily intervention across a wide area.
Lux 2 & 4
For full specifications download the brochure
Lux 2 or Lux 4: How Much Coverage Do You Need?
Both Lux models share the same autonomous operation, concrete base, 45-hour battery runtime and single-person setup. The difference is output.
| Lux 2 | Lux 4 | |
| Lights | 2/4 x 80W High-Efficiency LED | 2/4 x 80W High-Efficiency LED |
| Solar Panels | 2 x 415W | 4 x 415W |
| Battery Capacity | 7.2 kWh | 14.4 kWh |
| Battery Redundancy | 4 days | 4 days |
| Mass | 1,800 kg | 1,950 kg |
Need a Towable Option?
The Lux 4 moves by forklift. If your site needs lighting that can be towed between locations by a light vehicle, the Omni Lighting range runs up to 75,000 lumens on an 8m electric articulated mast and is ADR compliant for towing.
Talk to The MTGA Team
Not sure if the Lux 4 suits your site? Get in touch and we’ll work through your lighting requirements.
