Lux 2 Lighting Tower

High Power Solar Light Tower Built to Run a Full Shift, Every Day, Without Intervention

The Lux 2 is a compact, solar-powered industrial lighting tower built for sites that need reliable, high-output lighting without generator fuel or manual operation. Two 80W high-efficiency LED lights deliver consistent illumination across a 14-hour duty cycle, engineered to run a full shift every day through winter without intervention. The astronomical clock controller turns the lights on at dusk and off at dawn automatically, with auto, on and off modes selectable manually or via Bluetooth smart controller.

At 1,800kg on a concrete base, it’s stable enough for exposed and off-road conditions. The hydraulic folding solar array and guarded 6m telescopic mast enable single-person setup. Forklift pockets built into the base mean repositioning takes a 2.5T forklift and a few minutes.

Request A Quote
  • GUARDED TELESCOPIC MAST
  • ADJUSTABLE POSITIONING LIGHTS
  • DURABLE POWDER-COATED STEEL FRAME
  • FOLDING SOLAR ARRAY
  • COMPACT AND FORKLIFT-MOVEABLE
  • A HUGE 45 HOUR RUNTIME ON BATTERY ONLY

See It in Use

Specifications

Run time on Battery Only
45 hours
Design Duty
Designed to operate 14 hours a day every day including winter. 100% up time usability.
Control
On/Off and Auto. Operating by an astronomical clock turning on and off with dawn and dusk.
Mass
Lux 2 - 1,800 kg
Base Type
Concrete Base
Lights
2/4 x 80W High-Efficiency LED
Lumens
Lux 2 - 29,400
Mast Type
6m Cable Actuated Telescopic
Supported Wind
100km/h if deployed, 145km/h stowed
Battery Redundancy
Up to 4 Days
Solar Panels
Lux 2 - 2 x 415W
Batteries
Lux 2 - 7.2 kWh 1 x 48V 150Ah LiFePO4

Why Choose This Product

  • Runs Itself, Dawn to Dusk, Every Day

    Runs Itself, Dawn to Dusk, Every Day

    The astronomical clock controller turns the Lux 2 on at dusk and off at dawn without manual input. Set it up, walk away and it operates on schedule. Lighting and solar settings are adjustable manually or via the Bluetooth-enabled smart controller if conditions or requirements change.
  • 45 Hours on Battery, Zero Sunlight

    45 Hours on Battery, Zero Sunlight

    Forty-five hours of battery runtime with no solar input means the Lux 2 keeps running through extended overcast periods without intervention. Designed to operate 14 hours a day every day including winter, 100% uptime usability.
  • Single-Person Setup

    Single-Person Setup

    The hydraulic folding solar array and guarded telescopic mast are engineered for safe, single-person deployment in challenging environments. No crew required to get it operational.
  • Forklift Moveable

    Forklift Moveable

    The concrete base includes forklift pockets for repositioning by any 2.5T forklift. Compact enough to store efficiently between deployments, quick to redeploy as site requirements change.

Built for Industrial Sites That Run After Dark

  • Mining

    Overnight operations, shift work and remote drill sites requiring consistent, unattended lighting without generator logistics.

  • Civil Construction

    Active work zones and access points on civil projects running night shifts or extended hours.

  • Agriculture

    Machinery maintenance, storage facilities and work areas on large properties where mains lighting isn't available.

  • Defence & Government

    Remote installations and forward deployments requiring self-sufficient, zero-emission lighting that operates without daily intervention.

Lux 2 & 4

For full specifications download the brochure

Lux 2 or Lux 4: How Much Coverage Do You Need?

Both Lux models share the same autonomous operation, concrete base, 45-hour battery runtime and single-person setup. The difference is output.

Lux 2Lux 4
Lights2/4 x 80W High-Efficiency LED2/4 x 80W High-Efficiency LED
Solar Panels2 x 415W4 x 415W
Battery Capacity7.2 kWh14.4 kWh
Battery Redundancy4 days4 days
Mass1,800 kg1,950 kg

Need Lighting For a Larger Area?

The Lux 2 suits single zones, access points and work areas where two lights cover the ground. The Lux 4 is the right call for larger open areas or anywhere you need to cover more ground from a single unit.

View the Lux 4

Talk to The MTGA Team

Not sure what solution is right for you? Our team will go through the details with you and provide a quote tailored to your operation.

Request A Quote

Frequently Asked Questions

What is the Lux 2 solar lighting tower and how does it work?
The Lux 2 is a compact, solar-powered lighting tower with two 80W high-efficiency LED lights on a 6m telescopic mast. An astronomical clock controller switches the lights on at dusk and off at dawn automatically, with manual or Bluetooth override, so it runs unattended with no generator or mains power required.
How long does the Lux 2 run on battery power alone?
The Lux 2 delivers up to 45 hours of runtime on battery only, with no solar input needed. With its 7.2kWh LiFePO4 battery and 14-hour daily design duty, it's built to operate every day through winter, including extended overcast periods, without intervention.
How do I get a quote for the Lux 2?
Request a quote through the MTGA website or contact the team directly. MTGA can also discuss customisation options, such as extended battery redundancy or a different mast height, to suit your site.
Can one person set up and move the Lux 2 lighting tower?
Yes. The hydraulic folding solar array and guarded telescopic mast are engineered for single-person deployment, with no crew required. Forklift pockets built into the concrete base also mean the unit can be repositioned with a 2.5T forklift in a few minutes.
How many lumens does the Lux 2 produce, and how does it compare to the Lux 4?
The Lux 2's two 80W LED lights produce 29,400 lumens, powered by a 2 x 415W solar array. The Lux 4 doubles the solar and battery capacity (4 x 415W panels, 14.4kWh battery) for larger open areas, while both models share the same 45-hour battery runtime, concrete base and single-person setup.
What industries and site conditions is the Lux 2 built for?
The Lux 2 is designed for overnight mining operations and remote drill sites, civil construction night shifts, agricultural machinery and storage areas without mains lighting, and defence and government installations needing self-sufficient, zero-emission lighting. It's rated to withstand 100km/h wind while deployed and 145km/h stowed.
Can the Lux 2 be customised for different site requirements?
Yes. MTGA can customise the Lux 2 with extended battery redundancy, a different mast height, or additional lighting configurations. The Lux 2 is designed and built in Perth, Western Australia.
