1000 Series Semi-Portable Base Station
High-Power Communication Base Station with Dual Redundancy and Full LTE Capability
The 1000 Series is a semi-portable communications base station built to replace a standard communications tower at sites with advanced, high-power requirements. Supporting more than 1600W of continuous power draw, it runs LTE applications for a single sector or cell, and keeps running with both battery and generator redundancy backing it up.
At 8–11 tonnes, it moves by off-road forklift or crane, and a single person can deploy the full 12–18 panel solar array and aluminium lattice mast in under 10 minutes. Equipment sits in a double-walled, air-conditioned insulated shelter or air-conditioned RU racks, keeping everything environmentally controlled regardless of what’s happening outside. Masts from 17 to 50 metres are supported, with headloads up to 200kg at apex. Fabricated in Perth on a galvanised skid frame with heavy gauge tube construction.
- SUPPORTS 20M+ TOWER OR STANDALONE SETUP
- SLIDING SOLAR PANEL ARRAY
- RAPID DEPLOY IN 10 MINUTES; MOVEABLE BY OFF-ROAD FORKLIFT OR CRANE
- SUPPORTS 1,000-1,600W CONTINUOUS POWER DRAW
- AIR-CONDITIONED DOUBLE-WALLED INSULATION SHELTER OR AIR-CONDITIONED RU RACKS
- BATTERY AND GENERATOR REDUNDANCY
See It in Use
Specifications
- Mass
- Approx. 8-11 tonnes
- Type
- Semi-Portable Base Station
- Power Output
- 1,600+W
- Mast Height
- 17 - 50m
- Mast Type
- Aluminium lattice or articulated, pneumatic or standalone rapid deploy
- Supported Headload
- 90 - 200 kg+ (at apex)
- Supported Wind
- 145km/h+ - Wind Region B/C
- Battery Redundancy
- More than 5 days
- Generator Redundancy
- 6 Days (200L Tank)
- Solar Panels
- 12-18 x 400 - 500W
- Batteries
- Over 100 kWh
- Battery Configuration
- 48V
- Power Backup
- 3.0 kVA 48V/240V Yanmar Generator
- Enclosures
- 1 x Double-walled insulated shelter, or air-conditioned racks with mild steel enclosures
Why Choose This Product
Made in Australia for Australian Conditions
Fabricated at our Perth workshop on a galvanised skid frame with heavy gauge tube construction. Built to handle extreme heat, dust and the kind of sustained operational demands that large-scale mine sites put on communications infrastructure.
1000–1600W Continuous Power, Fully Redundant
Twelve to eighteen solar panels deliver serious continuous power, backed by more than five days of battery redundancy and six days of generator redundancy from a 200L tank. For operations where communications failure isn't an option, the dual redundancy setup keeps the system live.
Air-Conditioned Equipment Housing
Communications hardware performs best when it's kept cool and dust-free. The 1000 Series houses all equipment in either a double-walled insulated shelter or air-conditioned RU racks, keeping everything environmentally controlled in conditions that would compromise standard enclosures.
Fully Customisable to Your Requirements
Mast height, panel count, battery capacity, communications systems, all of it can be specified around your operation. Tell our team what you need to achieve and they'll engineer the 1000 Series to deliver it.
Where the 1000 Series Gets Used
Mining
Large mine sites requiring single-sector or cell-level LTE communications coverage with the power output and redundancy to run 24 hours a day, every day.Defence & Government
Major remote installations, long-term operational deployments and large-scale emergency response requiring permanent-standard communications infrastructure in a semi-mobile format.Telecommunications
Replacing or supplementing fixed tower infrastructure in locations where permanent construction isn't practical but full-capability LTE coverage is required.
1000 Series Semi-Portable Base Station
For full specifications download the brochure
How Deployment Works
The 1000 Series is a skid-based unit moved into position by off-road forklift or crane. Once positioned, a single operator deploys the full solar array and mast in under 10 minutes. It can operate as a standalone base station or as a power supply for an existing tower on site. Relocation is straightforward when operational requirements shift.
Need Multi-Sector Coverage or Higher Power?
The 2000 Series is MTGA's flagship base station, fully custom built for operations requiring multi-sector LTE capability, 4000W+ continuous power and masts up to 50m+. For the most demanding communications requirements on the largest operations, it's the top of the range.
Talk to The MTGA Team
Not sure what solution is right for you? Our team will go through the details with you and provide a quote tailored to your operation.
